FSAF528 is a mounted spherical roller bearing unit designed for heavy loads, misalignment, and harsh industrial environments.
Typical applications: Heavy-duty industrial support, split block housing replacements, conveyors, bulk handling, aggregate and process equipment.
Specifications
| Part Number |
FSAF528 |
| Bearing Type |
Spherical roller bearing split block housed unit |
| Configuration |
Split block housed unit |
| Shaft Diameter |
4-15/16 in |
| A |
6.00 in |
| B |
11.73 in |
| D |
3.38 in |
| E (min) |
15.98 in |
| E (max) |
17.13 in |
| F |
20.12 in |
| G |
5.87 in |
| H |
2.40 in |
| J (Bolt Size) |
1" (4) |
| L |
7.64 in |
| Spherical Roller Bearing P/N |
22228CAKW33C3 |
| Adapter Assembly P/N |
HA3128_4-15/16" |
| Seal P/N |
LER 122 |
| End Cover P/N |
A528 |
| Stabilizing Ring P/N |
SR-28-0 |
| Pillow Block Assembly P/N |
FSAF 22528 |
| Housing Material |
Cast iron |
| Bearing Material |
52100 bearing steel with brass cage |
| Bore Type |
Tapered bore |
| Clearance |
C3 |
| Seal Material |
Aluminum labyrinth seal |
Need bulk pricing or availability? Contact us for volume quotes and sourcing support.
